汉钟低温LBI系列螺杆机组

机组运行范围:-50℃~10℃:机组带经济器运行，大大提高系统运行效率，降低运行成本；

邮箱：

123@123.com

电话：

0575-83082895

在线咨询

推荐产品

还在决定吗？先拿样品，联系我们！

所属分类：

汉钟螺杆机组

关键词：

螺杆机组

活塞机组

涡旋机组

冷库冷源

产品描述

机组特点：

机组运行范围:-50℃~10℃:机组带经济器运行，大大提高系统运行效率，降低运行成本；

机组配置齐全，主要部件及控制元件均采用知名品牌，稳定性高；

机组结构紧凑，高度集成化，节约机房面积，安装维护方便；

广泛应用于冷冻冷藏、工业制程冷却、冷冻干燥等多个行业与领域。

机组型号 Unit Model	压缩机型号 Com.Model ( Hanbell)	压缩机数量 Com. Quantity	冷凝温度 Condensing Temp.(℃)	制冷量 Qo[Kw] Cooling Capacity					输入功率 Pe[Kw] Input Power					储液器 Liquid Receiver ( L)	供液管接口 Supply Pipe (mm)	吸气管接口 Suction Pipe (mm)	排气管接口 Discharge Pipe (mm)	油出口 Oil outlet (mm)	外形尺寸 Dimension(mm) (L×W×H)
				蒸发温度Evaporation Temp.(℃)
				-20		-25		-30		-35		-40
				Qo	Pe	Qo	Pe	Qo	Pe	Qo	Pe	Qo	Pe
EPL-HBH-30LY	LBⅡ-100-PLUS（30HP）	1	35	53.8	24.7	43.0	23.4	34.8	22.6	28.1	22.1	22.3	20.6	80	Φ28	Φ57	Φ45	Φ22	2200×1450×2150
			40	49.5	26.8	41.6	26.5	33.1	25.5	26.6	24.0	21.0	22.6
			45	47.1	30.1	40.1	30.1	31.6	28.0	24.9	26.3	19.5	24.6
EPL-BHBH2-60LY		2	35	107.6	49.4	86.0	46.8	69.6	45.2	56.2	44.2	44.6	41.2	150	Φ35	Φ89	Φ57	Φ28	2400×1800×2200
			40	99.0	53.6	83.2	53.0	66.2	51.0	53.2	48.0	42.0	45.2
			45	94.2	60.2	80.2	60.2	63.2	56.0	49.8	52.6	39.0	49.2
EPL-BHBH3-90LY		3	35	161.4	74.1	129.0	70.2	104.4	67.8	84.3	66.3	66.9	61.8	200	Φ45	Φ108	Φ76	Φ28	3100×1800×2200
			40	148.5	80.4	124.8	79.5	99.3	76.5	79.8	72.0	63.0	67.8
			45	141.3	90.3	120.3	90.3	94.8	84.0	74.7	78.9	58.5	73.8
EPL-BHBH4-120LY		4	35	215.2	98.8	172.0	93.6	139.2	90.4	112.4	88.4	89.2	82.4	250	Φ57	Φ133	Φ76	Φ28	4200×2000×2200
			40	198.0	107.2	166.4	106.0	132.4	102.0	106.4	96.0	84.0	90.4
			45	188.4	120.4	160.4	120.4	126.4	112.0	99.6	105.2	78.0	98.4
EPL-BHBH5-150LY		5	35	269.0	123.5	215.0	117.0	174.0	113.0	140.5	110.5	111.5	103.0	250	Φ57	Φ133	Φ89	Φ35	500020002200
			40	247.5	134.0	208.0	132.5	165.5	127.5	133.0	120.0	105.0	113.0
			45	235.5	150.5	200.5	150.5	158.0	140.0	124.5	131.5	97.5	123.0
EPL-HBH-40LY	LBⅡ-140-PLUS（40HP）	1	35	76.6	33.5	61.2	31.9	49.6	30.9	40.1	30.0	31.8	28.5	100	Φ28	Φ57	Φ45	Φ22	2200×1450×2150
			40	70.4	36.6	59.2	36.1	47.0	34.7	37.8	33.2	29.8	31.2
			45	67.0	40.9	57.1	41.0	45.0	38.8	35.5	36.3	27.8	34.0
EPL-BHBH2-80LY		2	35	153.2	67.0	122.4	63.8	99.2	61.8	80.2	60.0	63.6	57.0	200	Φ45	Φ89	Φ76	Φ28	2400×1800×2200
			40	140.8	73.2	118.4	72.2	94.0	69.4	75.6	66.4	59.6	62.4
			45	134.0	81.8	114.2	82.0	90.0	77.6	71.0	72.6	55.6	68.0
EPL-BHBH3-120LY		3	35	229.8	100.5	183.6	95.7	148.8	92.7	120.3	90.0	95.4	85.5	250	Φ57	Φ108	Φ76	Φ28	3100×1800×2200
			40	211.2	109.8	177.6	108.3	141.0	104.1	113.4	99.6	89.4	93.6
			45	201.0	122.7	171.3	123.0	135.0	116.4	106.5	108.9	83.4	102.0
EPL-BHBH4-160LY		4	35	306.4	134.0	244.8	127.6	198.4	123.6	160.4	120.0	127.2	114.0	300	Φ57	Φ133	Φ89	Φ35	4200×2000×2200
			40	281.6	146.4	236.8	144.4	188.0	138.8	151.2	132.8	119.2	124.8
			45	268.0	163.6	228.4	164.0	180.0	155.2	142.0	145.2	111.2	136.0
EPL-BHBH5-200LY		5	35	383.0	167.5	306.0	159.5	248.0	154.5	200.5	150.0	159.0	142.5	300	Φ57	Φ133	Φ89	Φ35	500020002200
			40	352.0	183.0	296.0	180.5	235.0	173.5	189.0	166.0	149.0	156.0
			45	335.0	204.5	285.5	205.0	225.0	194.0	177.5	181.5	139.0	170.0
EPL-HBH-55LY	LBⅡ-180-PLUS（55HP）	1	35	91.6	39.9	73.2	37.9	59.4	36.6	47.9	35.8	38.1	33.9	150	Φ28	Φ76	Φ45	Φ22	2200×1450×2150
			40	84.3	43.4	70.9	42.9	56.3	41.3	45.3	39.5	35.7	37.2
			45	80.2	48.5	68.3	48.7	53.9	46.2	42.5	43.2	33.2	40.5
EPL-BHBH2-110LY		2	35	183.2	79.8	146.4	75.8	118.8	73.2	95.8	71.6	76.2	67.8	200	Φ45	Φ108	Φ76	Φ28	2400×1800×2200
			40	168.6	86.8	141.8	85.8	112.6	82.6	90.6	79.0	71.4	74.4
			45	160.4	97.0	136.6	97.4	107.8	92.4	85.0	86.4	66.4	81.0
EPL-BHBH3-165LY		3	35	274.8	119.7	219.6	113.7	178.2	109.8	143.7	107.4	114.3	101.7	250	Φ57	Φ133	Φ76	Φ28	3100×1800×2200
			40	252.9	130.2	212.7	128.7	168.9	123.9	135.9	118.5	107.1	111.6
			45	240.6	145.5	204.9	146.1	161.7	138.6	127.5	129.6	99.6	121.5
EPL-BHBH4-220LY		4	35	366.4	159.6	292.8	151.6	237.6	146.4	191.6	143.2	152.4	135.6	300	Φ57	Φ159	Φ89	Φ35	4200×2000×2200
			40	337.2	173.6	283.6	171.6	225.2	165.2	181.2	158.0	142.8	148.8
			45	320.8	194.0	273.2	194.8	215.6	184.8	170.0	172.8	132.8	162.0
EPL-BHBH5-275LY		5	35	458.0	199.5	366.0	189.5	297.0	183.0	239.5	179.0	190.5	169.5	400	Φ57	Φ159	Φ89	Φ35	500020002200
			40	421.5	217.0	354.5	214.5	281.5	206.5	226.5	197.5	178.5	186.0
			45	401.0	242.5	341.5	243.5	269.5	231.0	212.5	216.0	166.0	202.5
EPL-HBH-60LY	LBⅡ-200-PLUS（60HP）	1	35	105.9	45.6	84.6	43.4	68.6	42.0	55.4	40.9	44.0	39.0	150	Φ35	Φ89	Φ76	Φ28	2200×1450×2150
			40	97.4	49.9	81.9	49.2	65.1	47.4	52.3	45.4	41.3	42.7
			45	92.7	55.8	79.0	55.8	62.3	54.0	49.1	49.8	38.4	46.6
EPL-BHBH2-120LY		2	35	211.8	91.2	169.2	86.8	137.2	84.0	110.8	81.8	88.0	78.0	250	Φ57	Φ108	Φ76	Φ28	2400×1800×2200
			40	194.8	99.8	163.8	98.4	130.2	94.8	104.6	90.8	82.6	85.4
			45	185.4	111.6	158.0	111.6	124.6	108.0	98.2	99.6	76.8	93.2
EPL-BHBH3-180LY		3	35	317.7	136.8	253.8	130.2	205.8	126.0	166.2	122.7	132.0	117.0	300	Φ57	Φ133	Φ89	Φ35	3100×1800×2200
			40	292.2	149.7	245.7	147.6	195.3	142.2	156.9	136.2	123.9	128.1
			45	278.1	167.4	237.0	167.4	186.9	162.0	147.3	149.4	115.2	139.8
EPL-BHBH4-240LY		4	35	423.6	182.4	338.4	173.6	274.4	168.0	221.6	163.6	176.0	156.0	300	Φ57	Φ159	Φ89	Φ35	4500×2200×2200
			40	389.6	199.6	327.6	196.8	260.4	189.6	209.2	181.6	165.2	170.8
			45	370.8	223.2	316.0	223.2	249.2	216.0	196.4	199.2	153.6	186.4
EPL-BHBH5-300LY		5	35	529.5	228.0	423.0	217.0	343.0	210.0	277.0	204.5	220.0	195.0	500	Φ76	Φ159	Φ108	Φ45	540022002350
			40	487.0	249.5	409.5	246.0	325.5	237.0	261.5	227.0	206.5	213.5
			45	463.5	279.0	395.0	279.0	311.5	270.0	245.5	249.0	192.0	233.0
EPL-HBH-70LY	LBⅡ-230-PLUS（70HP）	1	35	122.4	52.0	91.3	63.5	79.3	47.7	64.0	46.6	50.8	44.6	200	Φ35	Φ89	Φ76	Φ28	2400×1700×2150
			40	112.6	56.7	94.6	55.8	75.2	53.7	60.4	52.8	47.7	48.8
			45	107.1	63.4	91.3	63.5	72.0	61.2	56.7	56.8	44.4	53.2
EPL-BHBH2-140LY		2	35	244.8	104.0	182.6	127.0	158.6	95.4	128.0	93.2	101.6	89.2	300	Φ57	Φ108	Φ76	Φ28	2600×2000×2200
			40	225.2	113.4	189.2	111.6	150.4	107.4	120.8	105.6	95.4	97.6
			45	214.2	126.8	182.6	127.0	144.0	122.4	113.4	113.6	88.8	106.4
EPL-BHBH3-210LY		3	35	367.2	156.0	273.9	190.5	237.9	143.1	192.0	139.8	152.4	133.8	400	Φ57	Φ133	Φ89	Φ35	3400×2000×2300
			40	337.8	170.1	283.8	167.4	225.6	161.1	181.2	158.4	143.1	146.4
			45	321.3	190.2	273.9	190.5	216.0	183.6	170.1	170.4	133.2	159.6
EPL-BHBH4-280LY		4	35	489.6	208.0	365.2	254.0	317.2	190.8	256.0	186.4	203.2	178.4	500	Φ76	Φ159	Φ108	Φ45	450022002200
			40	450.4	226.8	378.4	223.2	300.8	214.8	241.6	211.2	190.8	195.2
			45	428.4	253.6	365.2	254.0	288.0	244.8	226.8	227.2	177.6	212.8
EPL-BHBH5-350LY		5	35	612.0	260.0	456.5	317.5	396.5	238.5	320.0	233.0	254.0	223.0	600	Φ76	Φ159	Φ133	Φ45	540022002450
			40	563.0	283.5	473.0	279.0	376.0	268.5	302.0	264.0	238.5	244.0
			45	535.5	317.0	456.5	317.5	360.0	306.0	283.5	284.0	222.0	266.0
EPL-HBH-75LY	LBⅡ-250-PLUS（75HP）	1	35	147.6	60.0	117.9	57.1	95.6	55.2	77.2	53.7	61.3	52.4	200	Φ35	Φ89	Φ76	Φ28	2400×1700×2150
			40	135.8	65.4	114.1	64.6	90.7	62.1	72.9	60.7	57.5	57.3
			45	129.2	73.0	110.0	73.2	86.8	70.7	68.4	66.7	53.5	62.4
EPL-BHBH2-150LY		2	35	295.2	120.0	235.8	114.2	191.2	110.4	154.4	107.4	122.6	104.8	300	Φ57	Φ133	Φ89	Φ35	2600×2000×2200
			40	271.6	130.8	228.2	129.2	181.4	124.2	145.8	121.4	115.0	114.6
			45	258.4	146.0	220.0	146.4	173.6	141.4	136.8	133.4	107.0	124.8
EPL-BHBH3-225LY		3	35	442.8	180.0	353.7	171.3	286.8	165.6	231.6	161.1	183.9	157.2	500	Φ76	Φ159	Φ108	Φ45	3400×2000×2300
			40	407.4	196.2	342.3	193.8	272.1	186.3	218.7	182.1	172.5	171.9
			45	387.6	219.0	330.0	219.6	260.4	212.1	205.2	200.1	160.5	187.2
EPL-BHBH4-300LY		4	35	590.4	240.0	471.6	228.4	382.4	220.8	308.8	214.8	245.2	209.6	600	Φ89	Φ159	Φ133	Φ57	450022002200
			40	543.2	261.6	456.4	258.4	362.8	248.4	291.6	242.8	230.0	229.2
			45	516.8	292.0	440.0	292.8	347.2	282.8	273.6	266.8	214.0	249.6
EPL-BHBH5-375LY		5	35	738.0	300.0	589.5	285.5	478.0	276.0	386.0	268.5	306.5	262.0	800	Φ89	Φ219	Φ133	Φ57	540022002450
			40	679.0	327.0	570.5	323.0	453.5	310.5	364.5	303.5	287.5	286.5
			45	646.0	365.0	550.0	366.0	434.0	353.5	342.0	333.5	267.5	312.0
EPL-HBH-85LY	LBⅡ-280-PLUS（85HP）	1	35	168.5	64.7	134.6	61.4	109.1	59.3	88.1	57.9	70.0	56.4	250	Φ45	Φ89	Φ76	Φ28	2400×1700×2150
			40	155.0	70.4	130.3	69.4	103.5	66.7	83.2	65.2	65.7	64.0
			45	147.5	78.8	125.6	78.8	99.1	76.0	78.1	73.8	61.1	68.6
EPL-BHBH2-170LY		2	35	337.0	129.4	269.2	122.8	218.2	118.6	176.2	115.8	140.0	112.8	400	Φ57	Φ133	Φ89	Φ35	2600×2000×2200
			40	310.0	140.8	260.6	138.8	207.0	133.4	166.4	130.4	131.4	128.0
			45	295.0	157.6	251.2	157.6	198.2	152.0	156.2	147.6	122.2	137.2
EPL-BHBH3-255LY		3	35	505.5	194.1	403.8	184.2	327.3	177.9	264.3	173.7	210.0	169.2	500	Φ76	Φ159	Φ108	Φ45	3400×2000×2300
			40	465.0	211.2	390.9	208.2	310.5	200.1	249.6	195.6	197.1	192.0
			45	442.5	236.4	376.8	236.4	297.3	228.0	234.3	221.4	183.3	205.8
EPL-BHBH4-340LY		4	35	674.0	258.8	538.4	245.6	436.4	237.2	352.4	231.6	280.0	225.6	600	Φ89	Φ159	Φ133	Φ57	450022002200
			40	620.0	281.6	521.2	277.6	414.0	266.8	332.8	260.8	262.8	256.0
			45	590.0	315.2	502.4	315.2	396.4	304.0	312.4	295.2	244.4	274.4
EPL-BHBH5-425LY		5	35	842.5	323.5	673.0	307.0	545.5	296.5	440.5	289.5	350.0	282.0	1000	Φ89	Φ219	Φ133	Φ57	540022002450
			40	775.0	352.0	651.5	347.0	517.5	333.5	416.0	326.0	328.5	320.0
			45	737.5	394.0	628.0	394.0	495.5	380.0	390.5	369.0	305.5	343.0
EPL-HBH-100LY	LBⅡ-360-PLUS（100HP）	1	35	211.3	76.7	168.9	72.8	136.9	70.4	110.6	68.5	87.8	66.7	250	Φ45	Φ108	Φ76	Φ28	2400×1700×2150
			40	194.4	83.6	163.4	82.4	129.9	79.2	104.4	77.2	82.4	75.8
			45	185.1	93.4	157.6	93.6	124.3	90.1	98.0	87.5	76.6	83.1
EPL-BHBH2-200LY		2	35	422.6	153.4	337.8	145.6	273.8	140.8	221.2	137.0	175.6	133.4	400	Φ57	Φ159	Φ89	Φ35	320020002250
			40	388.8	167.2	326.8	164.8	259.8	158.4	208.8	154.4	164.8	151.6
			45	370.2	186.8	315.2	187.2	248.6	180.2	196.0	175.0	153.2	166.2
EPL-BHBH3-300LY		3	35	633.9	230.1	506.7	218.4	410.7	211.2	331.8	205.5	263.4	200.1	600	Φ76	Φ219	Φ133	Φ45	420020002250
			40	583.2	250.8	490.2	247.2	389.7	237.6	313.2	231.6	247.2	227.4
			45	555.3	280.2	472.8	280.8	372.9	270.3	294.0	262.5	229.8	249.3
EPL-BHBH4-400LY		4	35	845.2	306.8	675.6	291.2	547.6	281.6	442.4	274.0	351.2	266.8	800	Φ89	Φ219	Φ133	Φ57	5400×2300×2550
			40	777.6	334.4	653.6	329.6	519.6	316.8	417.6	308.8	329.6	303.2
			45	740.4	373.6	630.4	374.4	497.2	360.4	392.0	350.0	306.4	332.4
EPL-BHBH5-500LY		5	35	1056.5	383.5	844.5	364.0	684.5	352.0	553.0	342.5	439.0	333.5	1000	Φ89	Φ219	Φ133	Φ57	640023002650
			40	972.0	418.0	817.0	412.0	649.5	396.0	522.0	386.0	412.0	379.0
			45	925.5	467.0	788.0	468.0	621.5	450.5	490.0	437.5	383.0	415.5
EPL-HBH-125LY	LBⅡ-410-PLUS（125HP）	1	35	248.0	89.2	198.1	84.8	160.6	81.8	129.7	79.7	103.0	77.7	300	Φ45	Φ108	Φ76	Φ28	2400×1700×2150
			40	228.1	97.3	191.8	95.9	152.4	92.1	122.5	89.8	96.7	88.1
			45	217.2	108.7	184.9	108.8	145.9	104.8	115.0	101.6	89.9	97.1
EPL-BHBH2-250LY		2	35	496.0	178.4	396.2	169.6	321.2	163.6	259.4	159.4	206.0	155.4	500	Φ76	Φ159	Φ108	Φ45	320020002250
			40	456.2	194.6	383.6	191.8	304.8	184.2	245.0	179.6	193.4	176.2
			45	434.4	217.4	369.8	217.6	291.8	209.6	230.0	203.2	179.8	194.2
EPL-BHBH3-375LY		3	35	744.0	267.6	594.3	254.4	481.8	245.4	389.1	239.1	309.0	233.1	600	Φ89	Φ219	Φ133	Φ45	440020002450
			40	684.3	291.9	575.4	287.7	457.2	276.3	367.5	269.4	290.1	264.3
			45	651.6	326.1	554.7	326.4	437.7	314.4	345.0	304.8	269.7	291.3
EPL-BHBH4-500LY		4	35	992.0	356.8	792.4	339.2	642.4	327.2	518.8	318.8	412.0	310.8	800	Φ89	Φ219	Φ133	Φ57	5800×2300×2650
			40	912.4	389.2	767.2	383.6	609.6	368.4	490.0	359.2	386.8	352.4
			45	868.8	434.8	739.6	435.2	583.6	419.2	460.0	406.4	359.6	388.4
EPL-BHBH5-625LY		5	35	1240.0	446.0	990.5	424.0	803.0	409.0	648.5	398.5	515.0	388.5	1500	Φ89	Φ273	Φ159	Φ57	680024002750
			40	1140.5	486.5	959.0	479.5	762.0	460.5	612.5	449.0	483.5	440.5
			45	1086.0	543.5	924.5	544.0	729.5	524.0	575.0	508.0	449.5	485.5
